The preamp sections are based on a layout of two 12AX7's in Channel 1 and one EF86 in Channel 2. The two 12AX7's in Channel 1 create a parallel-triode circuit with interactive bass and treble. The one EF86 in Channel 2 consists of a high-gain pentode coupled to a six-position tone switch. Outright benefits include quick dial-in of new tones and an easy return to the settings you learn to prefer. Also "high treble" cut control, master volume, with a bypass feature that offers flexible control of the power amp section. The power amp is fed by a 12AX7 phase inverter, which drives four EL84 power tubes. The rectifier circuit gives you the flexibility of using one 5AR4 for a quick attack or you can use two 5V4's for a smooth round response. Other professional features include an effects loop, half power-mode switch (a conservative 30 watts switching to 15 watts), output impedance selector (4, 8, 16 ohms) and a speaker phase-reverse switch.
Class A refers to a high performance style of circuitry used in vacuum tube audio devices to extract maximum efficiency from power tubes. A constant high voltage signal is sent through the power stage without the forced negative feedback (or "cool down cycle") inherent in the Class A/B design. Matchless amplifiers rely on superior design, construction and components to manage the power of true Class A operation. Matchless Class A amplifiers provide an "alive" response, true tone, rich harmonics and smooth transition into distortion.
If you are looking for circuit boards in a Matchless amplifier, you won't find them. Matchless amplifiers are point-to-point wired, using military-spec components and hand wound transformers, without circuit boards of any kind. While these construction methods are more difficult and expensive than others, they are necessary to achieve the incomparable sound quality, reliability and ruggedness of a MATCHLESS.
Brand: Matchless Amplifiers
Watt: 30 / 15
Rectifier: GZ34 (5AR4) (Two 5U4s Can Be Used Instead Of GZ34)
Front panel: Channel 1 Volume, Treble, Bass, Channel 2 Volume, Six-Position Tone Switch, Cut control, By-passable Master Volume
Back panel: Effect Loop, Half Power Switch, Output Impedance Selector (4, 8, 16 ohms), Speaker Phase-Reverse Switch, 2 AC Receptacles
Class type: A
Number of Channels: 2
Master volume: By-Passable Master
Power Tubes: EL84
Number of Power tubes: 4
Preamp Tubes: EF-86, 12AX7
Number of Preamp tubes: 4
Circuit Type: P-T-P
Effect loop: Yes
Half power switch: Yes
Cabinet Type: Head, 1X12 Combo, 2X12 Combo
Speakers: Matchless Modified Celestion Speakers
Cab Color: Black (Other Solid and Two Tone Colors Optional - Call For Prices)
Sales Price: List: HC30 Head - $2,861, SC30 1X12 Combo - $3,303, DC30 2X12 Combo - $3,599. ( Call For Our Best Price )
Rental Price: Head - $125 Per Day or $500 Per Week, Combo - $150 Per Day or $600 Per Week
